Standards: CENELEC, IEC, NEC

Zones:

• Zone 1 and Zone 2
• Zone 21 and Zone 22
• Class I, Zone 1 and Zone 2
• Class I, Division 2, Groups C, D
• Class I, Division 1, Groups C, D

Explosion protection:

• IECEX(Gas and dust):
  • Ex d e IIB T□1) Gb
  • Ex tb IIIC T□1) Db IP66
• ATEX(Gas and dust):
  • II 2 G Ex db e IIB T□1) Gb
  • II 2 D Ex tb IIIC T□1) Db IP66

Material:

• Enclosure: Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021)
• Glass cover: Toughened glass, stands 4J impact
• Internal reflector: High-purity aluminium
• Exposed fastener: Stainless steel

Ballast: Electromagnetic ballast, rapid starting, stable performance

Lamp holder: E27~E40

Available lamp and lamp power (W):

• High pressure sodium lamp (HSE): 150W, 250W
• High pressure mercury lamp (HME): 250W
• Metal halide lamp (HIE): 250W

Rated luminous flux: 5800~42500lm

Rated voltage: 220~240V AC 50Hz (60Hz is optional)

Earthing protection: M5 (internal & external earth bolts)

Degree of protection: IP66

Ambient temperature: -60°C~+55°C

Terminal: 3 x 1.5~2.5mm² (L+N+PE)

Cable entries: 2 x Φ21: 1 x M20 x 1.5 cable gland (DQM-I Ex e), 1 x M20 x 1.5 plug

Available cable outer diameter: Φ10~Φ14 (mm)

Weight: 8.45~115kg
