Explosion protection to:

• CENELEC
• IEC
• NEC

Can be used in:

• Zone 1 and Zone 2
• Zone 21 and Zone 22
• Class I, Zone 1 and Zone 2
• Class I, Division 2, Group A, B, C, D

Explosion protection:

• IECEx (Gas and dust): Ex db op is llC T6 Gb; Ex tb op is llIC T80’℃ Db
• ATEX (Gas and dust): II 2 G Ex db op is llC T6 Gb; II 2 D Ex tb op is llIC T80’℃ Db

Material:

• Enclosure: Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021).
• Glass cover: Toughened glass, impact resistance and high light transmission.
• Exposed fastener: Stainless steel.

LED driver: Wide voltage input, CC-CV (constant current – constant voltage) output, power factor ≥0.95, with protection against circuit and anti-electromagnetic interference, etc.

Rated voltage:

• 100~277V AC 50/60Hz
• 100~250V DC
• 12~36V 50/60Hz
• 12~48V DC

Lamp:

• Lamp specification: International brand of LED module
• Lamp power (W): 9W
• Colour Temperature (CCT): 5700K (Note: cool white is available in general. Warm white or nature white is optional,.please specify when ordering.)

Earthing protection: M5 (internal & external earth bolts)

Degree of protection: IP66/IP67

Ambient temperature: -40℃~+55℃

Terminal: 3 x 1.5~2.5mm² (L+N+PE).

Cable entries: M20 x1.5

Cable gland: Supplied with seal gasket and gland nut

Available cable outer diameter: Φ16~Φ20 (mm).
