Explosion protection to

• CENELEC
• IEC

Can be used in:

• Zone 1 and Zone 2
• Zone 21 and Zone 22

Explosion Protection Ratings:

• IECEx (Gas and dust): Ex d e ib mb px IIC T4 Gb; Ex ibD tb pD IIIC T130°C Db IP66
• ATEX (Gas and dust): II 2 G Ex d e ib mb px IIC T4 Gb; II 2 D Ex ib tb pD IIIC T130°C Db IP66

Product Parameters

Model: BKF(R)-50/220

• Cooling capacity: 5275W (18000* BTU)
• Heating capacity: 5600W
• Rated voltage / Frequency: 220~240V/50Hz or 220~240V/60Hz
• Input power: 2P
• Cooling input power / Current: 1432W / 6.5A
• Heating input power / Current: 1690W / 7.68A
• Application areas: 22~37m²
• Sound level: Indoor 43* dB / Outdoor 54* dB
• Outline dimensions (L x W x H):
  • Indoor unit: 960 x 385 x 245* mm
  • Outdoor unit: 1197×600×470* mm
  • Control box: 500×542×207* mm
• Weight: Indoor 21.00* kg / Outdoor 146.00* kg / Control box 30 kg

Model: BKF(R)-71/220

• Cooling capacity: 7032W (24000* BTU)
• Heating capacity: 6600W
• Rated voltage / Frequency: 220~240V/50Hz or 220~240V/60Hz
• Input power: 3P
• Cooling input power / Current: 2200W / 10A
• Heating input power / Current: 2600W / 11.8A
• Application areas: 27~44 m²
• Sound level: Indoor 44* dB / Outdoor 54* dB
• Outline dimensions (L x W x H):
  • Indoor unit: 1075×400×275* mm
  • Outdoor unit: 1222×685×470* mm
  • Control box: 500×542×207* mm
• Weight: Indoor 25.00* kg / Outdoor 148.00* kg / Control box 30 kg
