SCHUCH QUALITY – YOUR ADVANTAGE
Intelligent microprocessor-controlled emergency electronics with integral electronic ballast (EVG):
- End-of-life protection” (acc. to the latest standards IEC 60079-7 with 2 safety circuits
- test 1 and test 2)
- Multi-function LED with coded indication of function, status and possible failures of
- the electronics and batteries
- Special signal whenever there is an EOL situation (flashing red LED)
Application:Hazardous areas in Zones 2 and 22 as safety illumination and as information or escape route lighting
Mechanical design:Housing: Glass fibre reinforced polyester
Cover: Clear polycarbonate with internal prisms, hinged and detachable
Reflector: White painted sheet steel, hinged and removable
Central locking system: Operated by a hexagonal socket key 13mm
Isolating switches: 2 Switches cutting off all poles when the light fitting is opened
Mandatory optical indicator showing the actual position of the switch
Mechanical design:Housing: Glass fibre reinforced polyester
Cover: Clear polycarbonate with internal prisms, hinged and detachable
Reflector: White painted sheet steel, hinged and removable
Central locking system: Operated by a hexagonal socket key 13mm
Isolating switches: 2 Switches cutting off all poles when the light fitting is opened
Mandatory optical indicator showing the actual position of the switch
Connection terminals: Standard: L1 + L1’ +N + PE, up to 2.5 mm²
Cable entries: 2 entries M25 x 1.5 (2 cable glands, 1 with blanking plug enclosed)
Through wiring: Standard with looping of mains cable at one end 3 x 2.5mm²
Mounting: Side fixing brackets allow direct mounting on to walls or ceilings
